General Information

• Technology : Arc splitting
• Dimensions : W2,100×D2,300×H2,100 mm
• Else : Double wall stainless steel water-cooled furnace; Expert operating system; The diagnosis function through remote control

Capacity(24H)

• milling cutter
  • D6×50 mm = 1,800×5 = 9,000
  • D16×95 mm = 450×5= 2,250
• Insert
  • D20×H6 mm = 2,340×5 =11,700
• Hobs
  • D80×180 mm =24×5= 120

Turntable

• D436×H727 mm

Power

• 3×400V/85Kw

Target

• 727×178×18 mm (3Set)
• 200/400/400

Coating types

• Standards Coating
  • TiN, TiCN, TiAlN, AlTiN, MDT
• Coating can be selected
  • TiAlSiN, AlCrTiN, DLC, NF1

Vacuum/Plasma

• Vacuum chamber size
  • W800 x D800 x H1,150 mm
• Vacuum chamber capacity
  • 730 l
• Using plasma volume
  • D=550 x H720

Electrical/Software

• Industrial PC system
• Simple and easy diagnosis and description system
• Remote diagnosis through data machine or IP
• Back up image file
